Remote Control of Cottage Heating by Phone
Heating · Solar Power · No WiFi · Temperature Monitoring
Etabox enables remote control of cottage heating, ventilation, temperature monitoring and other electrical devices from your phone. You can start the heating before you arrive at the cottage, monitor temperature in real-time and receive alerts directly to your phone.
Works in 12V/24V solar power systems without 230V grid.
Works without fixed internet or WiFi router.
Monitor cottage indoor and outdoor temperatures in real-time.
Battery voltage visible in the app – set alert limits.
Receive alerts directly to your phone at any time.
Start heating in advance before arriving at the cottage.
Etabox does not require a separate WiFi connection or fixed internet. The device uses an internal IoT modem and operates with a SIM card.
This makes Etabox an excellent solution for cottages that don't have a fixed internet connection.
Etabox also works in solar power systems, as the operating voltage is 7V – 34V. The device can be connected directly to, for example, a 12V or 24V battery.
Many cottages use solar panels and batteries without regular 230V mains electricity. Etabox is well suited for such systems because it operates at low voltage and does not require a separate WiFi router.
The application can also monitor the operating voltage, so users can easily see the battery status remotely.
For example, when the battery voltage drops too low, an automatic notification can be sent to the phone.
Etabox can control various heating systems either directly or via a relay.
OUT1, OUT2 and OUT3 outputs provide the same operating voltage as Etabox is powered with. Outputs can be used, for example, for relay control or low-current heating device start-up.
When controlling larger loads, Etabox controls a standard 12V or 24V relay, which in turn switches on the actual load.
Etabox can be connected to control a standard relay that starts, for example:
The application can then start or stop the heating from anywhere.
Etabox includes two temperature sensors. Temperatures can be monitored in real-time from the application.
Alerts can be set in the application for situations such as:
Users can set their own alert limits and the text displayed in notifications.
Etabox can also control cottage ventilation.
For example, OUT1 can be connected to a relay that starts the ventilation fan remotely from the phone.
Ventilation can also be scheduled to start automatically at certain times.
All outputs can be controlled by:
With the pulse control feature, the output can be activated for a short period, for example to open a door or simulate a button press. The pulse length can be set between 1 – 9999 milliseconds.
IN1 and IN2 inputs can be used to monitor, for example:
Etabox has no separate usage, application or cloud service fees. You only pay the SIM card subscription fees to your chosen operator.
One device – complete cottage remote control. Works on solar power, without WiFi, no monthly fees.
View product →No. Etabox uses an internal IoT modem and operates with its own SIM card.
Yes. Etabox operates at 7V – 34V operating voltage and is well suited for 12V and 24V battery systems.
Yes. Etabox includes two temperature sensors and temperatures are displayed in real-time in the application.
Yes. The application can control Etabox outputs and start heating remotely.
Yes. Alerts can be created based on temperature, voltage or input status.
No. Etabox has no usage or cloud service fees. You only pay the SIM card subscription fees to your operator.
